| Specification |
| Network |
| Ethernet LAN data rates |
100,1000 Mbit/s |
| Ethernet interface type |
Gigabit Ethernet |
| Supported protocols |
L2VPN, IPv4, IPv6, L3VPN |
| Quality of Service (QoS) support |
Yes |
| Access Control List (ACL) |
Yes |
| Technical details |
| Operating temperature (T-T) |
32 – 104 °F |
| Fiber optic connector |
SFP+ |
| Ethernet LAN data rates |
100,1000 Mbit/s |
| Ethernet interface type |
Gigabit Ethernet |
| Compatibility |
Cisco ASR 9000 |
| Supported protocols |
L2VPN, IPv4, IPv6, L3VPN |
| Optical fiber |
| Fiber optic connector |
SFP+ |
| Data transmission |
| Switching capacity |
440 Gbit/s |
| Ports & interfaces |
| Installed SFP+ modules quantity |
2 |
| Ethernet LAN (RJ-45) ports |
2 |
| Performance |
| Compatibility |
Cisco ASR 9000 |
| Management features |
| Quality of Service (QoS) support |
Yes |
| Access Control List (ACL) |
Yes |
| Security |
| Access Control List (ACL) |
Yes |
| Protocols |
| Supported protocols |
L2VPN, IPv4, IPv6, L3VPN |
| Power |
| Power consumption (typical) |
170 W |
| Operational conditions |
| Storage temperature (T-T) |
-40 – 75 °C |
| Storage relative humidity (H-H) |
5 – 95% |
| Operating temperature (T-T) |
32 – 104 °F |
| Operating temperature (T-T) |
0 – 40 °C |
| Operating relative humidity (H-H) |
10 – 90% |
| Operating altitude |
-60 – 4000 m |
| Certificates |
| Safety |
UL/CSA/IEC/EN 60950-1, IEC/EN 60825 Laser Safety, ACA TS001, AS/NZS 60950, FDA – Code of Federal Regulations Laser Safety |
| Electromagnetic compatibility |
FCC Class A, ICES 003 Class A, AS/NZS 3548 Class A, CISPR 22 (EN55022) Class A, VCCI Class A, BSMI Class A, IEC/EN 61000-3-2: Power Line Harmonics, IEC/EN 61000-3-3: Voltage Fluctuations and Flicker, EN 50121-4: Railway EMC |
| Weight & dimensions |
| Weight |
9 kg |
| Dimensions (WxDxH) |
406.4 x 673.8 x 41.9 mm |
|
