Number of languages

32

Languages support

Multi

Type

IP security camera

Connectivity technology

Wired

Placement supported

Indoor & outdoor

Wide Dynamic Range (WDR)

Yes

Day/night mode

Yes

Alarm input/output

Yes

Form factor

Bullet

Product colour

White

Mounting type

Ceiling/wall

International Protection (IP) code

IP66

Adjustment shutter speed

Auto/Manual

Minimum illumination

0.0018 lx

Viewing angle, horizontal

39.42°

Viewing angle, vertical

22.14°

White balance

ATW, Auto, Daylight, Indoor, Lamp, Manual, Outdoor, Sodium lamp

Camera shutter type

Electronic

Camera shutter speed

1 – 1/100000 s

Yes

Camera tilt control

Yes

Progressive scan

Yes

Number of effective pixels (H x V)

2688 x 1520 pixels

Sensor type

CMOS

Yes

Optical sensor size

25.4 / 2.7 mm (1 / 2.7″)

Maximum aperture number

1.1

Fixed focus

Yes

Fixed focal length

8 mm

Night vision

40 m

LED type

IR

Noise reduction

Yes

Noise reduction technology

3D noise reduction

Video compression formats

H.264,H.265,MPEG

Maximum resolution

2688 x 1520 pixels

Supported graphics resolutions

176 x 144,320 x 240,352 x 288,384 x 288,704 x 480,704 x 576,1280 x 720 (HD 720),1280 x 960,1920 x 1080 (HD 1080),2688 x 1520

Supported video modes

240p,360p,480p,540p,576p,720p,768p,1080p,1440p,1520p

Frame rate

30 fps

Yes

Total megapixels

4 MP

Audio input channels

1

Audio formats supported

G.711,G.711 A-law,G.711 μ-law,G.726,MP2L2,PCM

Bluetooth

No

Ethernet interface type

Fast Ethernet

Networking standards

IEEE 802.1x,IEEE 802.3af

Quality of Service (QoS) support

Yes

Number of users

32 user(s)

Ethernet LAN

Yes

Wi-Fi

No

IPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP, UDP, IGMP, ICMP, DHCP, PPPoE

Maximum memory card size

128 GB

Card reader integrated

Yes

Built-in HDD

No

Compatible memory cards

MicroSD (TransFlash), MicroSDHC, MicroSDXC

RS-485 ports

1

Microphone in

Yes

Ethernet LAN (RJ-45) ports

1

DC-in jack

Yes

Connectivity technology

Wired

IP address filtering

Yes

HTTPS encryption

Yes

Web browser

Yes

Power source type

DC, PoE

Power consumption (max)

7.5 W

Power consumption (Power over Ethernet (PoE))

8 W

DC-in jack

Yes

DC output voltage

12

Operating temperature (T-T)

10 – 35 °C

Operating relative humidity (H-H)

0 – 95%

Package type

Box

Length

35.8 cm

Width

113.5 mm

Height

115.2 mm

Weight

1.76 kg

Number of cameras

1

Package type

Box

Manual

No

Cables included

LAN (RJ-45)

Video compression formats

H.264,H.265,MPEG
