| Performance |
| Antenna gain level (max) |
34 dBi |
| Frequency band |
5.1 – 5.8 GHz |
| Vertical beam width (5 GHz) |
3° |
| Horizontal beam width (5 GHz) |
3° |
| Features |
| Survival wind speed |
200 km/h |
| Front to back ratio |
42 dB |
| Isolation |
34 dB |
| Antenna gain level (max) |
34 dBi |
| Frequency band |
5.1 – 5.8 GHz |
| Voltage Standing Wave Ratio (VSWR) |
1.4:1 |
| Vertical beam width (5 GHz) |
3° |
| Polarization |
Dual polarization |
| Horizontal beam width (5 GHz) |
3° |
| Product colour |
White |
| Compatible products |
AF-5X |
| Technical details |
| Antenna gain level (max) |
34 dBi |
| Frequency band |
5.1 – 5.8 GHz |
| Voltage Standing Wave Ratio (VSWR) |
1.4:1 |
| Vertical beam width (5 GHz) |
3° |
| Polarization |
Dual polarization |
| Horizontal beam width (5 GHz) |
3° |
| Compatible products |
AF-5X |
| Harmonized System (HS) code |
85177100 |
| Colour |
| Product colour |
White |
| Weight & dimensions |
| Weight |
13.5 kg |
| Width |
1050 mm |
| Depth |
421 mm |
| Height |
1050 mm |
| Diameter |
105 cm |
| Packaging content |
| Quick installation guide |
Yes |
| Quantity per pack |
1 pc(s) |
| Logistics data |
| Quantity per pack |
1 pc(s) |
| Harmonized System (HS) code |
85177100 |
