| Performance |
| Antenna gain level (max) |
19.1 dBi |
| Frequency band |
5.15 – 5.85 GHz |
| Vertical beam width (5 GHz) |
2° |
| Vertical beam width |
123° |
| Horizontal beam width (5 GHz) |
4° |
| Horizontal beam width |
123° |
| Features |
| Antenna gain level (max) |
19.1 dBi |
| Frequency band |
5.15 – 5.85 GHz |
| Antenna type |
Sector antenna |
| Voltage Standing Wave Ratio (VSWR) |
1.5:1 |
| Vertical beam width (5 GHz) |
2° |
| Vertical beam width |
123° |
| Purpose |
Outdoor |
| Polarization |
Dual polarization |
| Mounting |
Wall |
| Horizontal beam width (5 GHz) |
4° |
| Horizontal beam width |
123° |
| Product colour |
White |
| Certification |
EN 302 326 DN2 |
| Technical details |
| Antenna gain level (max) |
19.1 dBi |
| Frequency band |
5.15 – 5.85 GHz |
| Antenna type |
Sector antenna |
| Voltage Standing Wave Ratio (VSWR) |
1.5:1 |
| Vertical beam width (5 GHz) |
2° |
| Vertical beam width |
123° |
| Purpose |
Outdoor |
| Polarization |
Dual polarization |
| Mounting |
Wall |
| Horizontal beam width (5 GHz) |
4° |
| Horizontal beam width |
123° |
| Harmonized System (HS) code |
85177100 |
| Colour |
| Product colour |
White |
| Certificates |
| Certification |
EN 302 326 DN2 |
| Weight & dimensions |
| Weight |
5.9 kg |
| Width |
700 mm |
| Depth |
135 mm |
| Height |
73 mm |
| Packaging content |
| Quantity per pack |
1 pc(s) |
| Logistics data |
| Quantity per pack |
1 pc(s) |
| Harmonized System (HS) code |
85177100 |
