| Performance |
| Antenna gain level (max) |
13 dBi |
| Frequency band |
2.4 GHz |
| Vertical beam width (2.4 GHz) |
2° |
| Horizontal beam width (2.4 GHz) |
7° |
| Features |
| Antenna gain level (max) |
13 dBi |
| Frequency band |
2.4 GHz |
| Antenna type |
Sector antenna |
| Voltage Standing Wave Ratio (VSWR) |
1.7:1 |
| Vertical beam width (2.4 GHz) |
2° |
| Purpose |
Outdoor |
| Polarization |
Dual polarization |
| Mounting |
Wall |
| Horizontal beam width (2.4 GHz) |
7° |
| Product colour |
White |
| Certification |
EN 302 326 DN2 |
| Technical details |
| Antenna gain level (max) |
13 dBi |
| Frequency band |
2.4 GHz |
| Antenna type |
Sector antenna |
| Voltage Standing Wave Ratio (VSWR) |
1.7:1 |
| Vertical beam width (2.4 GHz) |
2° |
| Purpose |
Outdoor |
| Polarization |
Dual polarization |
| Mounting |
Wall |
| Horizontal beam width (2.4 GHz) |
7° |
| Harmonized System (HS) code |
85177100 |
| Colour |
| Product colour |
White |
| Certificates |
| Certification |
EN 302 326 DN2 |
| Weight & dimensions |
| Weight |
2.4 kg |
| Width |
1390 mm |
| Depth |
122 mm |
| Height |
105 mm |
| Packaging content |
| Quantity per pack |
1 pc(s) |
| Logistics data |
| Quantity per pack |
1 pc(s) |
