| Performance |
| Antenna gain level (max) |
19.5 dBi |
| Frequency band |
5.15 – 6.875 GHz |
| Vertical beam width |
25° |
| Horizontal beam width |
30° |
| Features |
| Ultraviolet (UV) resistant |
Yes |
| Survival wind speed |
200 km/h |
| Housing material |
Aluminium, Polycarbonate (PC) |
| Mounting pipe |
25 – 70 mm |
| Isolation |
20 dB |
| International Protection (IP) code |
IPX6 |
| Wind load |
90 |
| Antenna gain level (max) |
19.5 dBi |
| Frequency band |
5.15 – 6.875 GHz |
| Antenna type |
Horn antenna |
| Vertical beam width |
25° |
| Purpose |
Outdoor |
| Polarization |
Dual polarization |
| Mounting |
Pole |
| Horizontal beam width |
30° |
| Product colour |
White |
| Compatible products |
airFiber 5XHD Radio (AF 5XHD), LTU Rocket, or airMAX Rocket Prism AC 5 GHz Radio (RP 5AC) |
| Technical details |
| Antenna gain level (max) |
19.5 dBi |
| Frequency band |
5.15 – 6.875 GHz |
| Antenna type |
Horn antenna |
| Vertical beam width |
25° |
| Purpose |
Outdoor |
| Polarization |
Dual polarization |
| Mounting |
Pole |
| Horizontal beam width |
30° |
| Compatible products |
airFiber 5XHD Radio (AF 5XHD), LTU Rocket, or airMAX Rocket Prism AC 5 GHz Radio (RP 5AC) |
| Colour |
| Product colour |
White |
| Weight & dimensions |
| Weight |
3.06 kg |
| Width |
224 mm |
| Depth |
380 mm |
| Height |
282 mm |
| Packaging content |
| Mounting kit |
Yes |
|
