Dimensions Ø 75 x 140 mm (Ø 2.95 x 5.51″)
Weight 300 g (10.58 oz)
Enclosure Injection-Molded Polycarbonate and Die-Cast Aluminum
Networking Interface (1) 10/100 Ethernet Port
Sensor ⁄” 4-Megapixel HDR Sensor
Lens EFL 3.6 mm, f/1.8
Night Mode IR LEDs with Mechanical IR Cut Filter
Microphone Yes
Button Factory Reset Button
Power Method 802.3af PoE or 24V Passive PoE
Power Supply 802.3af PoE Switch
Maximum Power Consumption
Standalone With Optional IR Extender
4W
9W
Mounting Wall/Ceiling/Pole
Operating Temperature -20 to 50° C (-4 to 122° F)
Operating Humidity 20 – 90% Noncondensing
Video
Video Compression H.264
Resolution 1080p Full HD (1920×1080)
Maximum Frame Rate 30 FPS
Image Settings Brightness, Contrast, Sharpness, Saturation, Noise Reduction, 50/60 Hz
General
Viewing Angle
Before Lens Correction After Lens Correction
Supported UniFi Video Version UniFi Video 3.8 (or Newer)
UniFi Video System Requirements 64-bit Microsoft Windows10/8/7, Ubuntu14.04 or 16.04, or Debian 7.0 System with
an Intel or Compatible 1.86 GHz (or Above) Processor and a Minimum of 4 GB RAM
