| Performance |
| Built-in processor |
Yes |
| Processor model |
Atheros MIPS 74Kc |
| Processor frequency |
720 MHz |
| Internal memory type |
DDR2 |
| Internal memory |
128 MB |
| Flash memory |
16 MB |
| Antenna gain level (max) |
27 dBi |
| Frequency band |
5 GHz |
| Features |
| Survival wind speed |
96 km/h |
| Wind load |
264.6 |
| LED indicators |
LAN, Power, WLAN |
| Antenna gain level (max) |
27 dBi |
| Frequency band |
5 GHz |
| Antenna type |
Directional antenna |
| Voltage Standing Wave Ratio (VSWR) |
1.5:1 |
| Polarization |
Dual polarization |
| Mounting |
Pole |
| Product colour |
White |
| Certification |
FCC, IC, CE |
| Power |
| Power consumption (max) |
8.5 W |
| Technical details |
| Antenna gain level (max) |
27 dBi |
| Frequency band |
5 GHz |
| Antenna type |
Directional antenna |
| Voltage Standing Wave Ratio (VSWR) |
1.5:1 |
| Polarization |
Dual polarization |
| Mounting |
Pole |
| Harmonized System (HS) code |
85177100 |
| Compliance certificates |
RoHS |
| Colour |
| Product colour |
White |
| Certificates |
| Certification |
FCC, IC, CE |
| Operational conditions |
| Operating temperature (T-T) |
-40 – 70 °C |
| Operating relative humidity (H-H) |
5 – 95% |
| Weight & dimensions |
| Weight |
3.15 kg |
| Width |
525 mm |
| Depth |
315 mm |
| Height |
525 mm |
| Logistics data |
| Harmonized System (HS) code |
85177100 |
| Other features |
| Dimensions (WxDxH) |
620 x 620 x 386 mm |
|
