| Specification |
| Data transmission |
| Ethernet LAN data rates |
1000,2500,5000,10000 Mbit/s |
| Maximum data transfer rate |
5800 Mbit/s |
| Performance |
| 2.4 GHz |
Yes |
| 5 GHz |
Yes |
| Reset button |
Yes |
| Frequency band |
2.4, 5, 6 GHz |
| Number of users |
300 user(s) |
| VLAN support |
Yes |
| Rate limiting |
Yes |
| Networking standards |
IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11be, IEEE 802.11k, IEEE 802.11n, IEEE 802.11r, IEEE 802.11v |
| Ethernet LAN data rates |
1000,2500,5000,10000 Mbit/s |
| Maximum data transfer rate |
5800 Mbit/s |
| MIMO type |
Multi User MIMO |
| MIMO |
Yes |
| Band steering |
Yes |
| Wireless LAN features |
| Frequency band |
2.4, 5, 6 GHz |
| Network |
| Number of users |
300 user(s) |
| Networking standards |
IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11be, IEEE 802.11k, IEEE 802.11n, IEEE 802.11r, IEEE 802.11v |
| Management features |
| VLAN support |
Yes |
| Rate limiting |
Yes |
| Access point management |
Wi-Fi schedule |
| Features |
| 6 GHz |
Yes |
| 2.4 GHz |
Yes |
| 5 GHz |
Yes |
| Frequency band |
2.4, 5, 6 GHz |
| Number of users |
300 user(s) |
| VLAN support |
Yes |
| Rate limiting |
Yes |
| Networking standards |
IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11be, IEEE 802.11k, IEEE 802.11n, IEEE 802.11r, IEEE 802.11v |
| Ethernet LAN data rates |
1000,2500,5000,10000 Mbit/s |
| Maximum data transfer rate |
5800 Mbit/s |
| Fast roaming |
Yes |
| MIMO type |
Multi User MIMO |
| MIMO |
Yes |
| Band steering |
Yes |
| Maximum data transfer rate (2.4 GHz) |
688 Mbit/s |
| Maximum data transfer rate (5 GHz) |
4300 Mbit/s |
| Fit AP mode features |
Hotspot 2.0 |
| Maximum data transfer rate (6 GHz) |
5800 Mbit/s |
| Spatial streams |
6 |
| Coverage area |
140 m² |
| Wireless meshing |
Yes |
| Maximum Tx power (2.4 GHz) |
23 dBmW |
| Maximum Tx power (5 GHz) |
26 dBmW |
| Maximum Tx power (6 GHz) |
24 dBmW |
| Security |
| Security algorithms |
PPSK |
| Ports & interfaces |
| Ethernet LAN (RJ-45) ports |
1 |
| Power |
| Power consumption (max) |
22 W |
| Power over Ethernet (PoE) |
Yes |
| Power over Ethernet (PoE) type supported |
PoE+ |
| Design |
| Housing material |
Metal, Polycarbonate (PC) |
| Placement |
Ceiling, Wall |
| Product colour |
White |
| Reset button |
Yes |
| LED indicators |
Status |
| Antenna |
| Antenna type |
Internal |
| Antenna gain level (max) |
6 dBi |
| Technical details |
| Reset button |
Yes |
| Compliance certificates |
CE, Federal Communications Commission (FCC), Industry Canada (IC) |
| Certificates |
| Compliance certificates |
CE, Federal Communications Commission (FCC), Industry Canada (IC) |
| Indication |
| LED indicators |
Status |
| Software |
| Fast roaming |
Yes |
| Weight & dimensions |
| Width |
206 mm |
| Depth |
32.5 mm |
| Weight |
750 g |
| Height |
206 mm |
| Packaging data |
| Mounting kit |
Yes |
| Packaging content |
| Mounting kit |
Yes |
| Quantity per pack |
1 pc(s) |
| Operational conditions |
| Operating relative humidity (H-H) |
5 – 95% |
| Operating temperature (T-T) |
-30 – 40 °C |
| Logistics data |
| Quantity per pack |
1 pc(s) |
|
| Meta Description |
WiFi 7 (802.11a/b/g/n/ac/ax/be), 6 GHz, 140 m² (1,500 ft²), 10/5/2.5/1 GbE, PoE+, 300+ clients, 206 x 32.5 mm, 750 g |
