Part # UDB-Pro
Condition: New
Availability: In Stock
| Data transmission | |
|---|---|
| Maximum data transfer rate | 866.7 Mbit/s |
| Antenna | |
| Antenna gain level (max) | 19 dBi |
| Antenna design | Internal |
| Antenna type | 2×2 |
| Wireless LAN features | |
| Signal strength | 25 dBm |
| Outdoor range | 5+ km |
| Frequency band | 5 GHz |
| Modulation | 16-QAM, 64-QAM, 256-QAM, BPSK, QPSK |
| Antenna gain level (max) | 19 dBi |
| Wi-Fi | Yes |
| Wi-Fi band | Single-band (5 GHz) |
| Top Wi-Fi standard | Wi-Fi 5 (802.11ac) |
| Antenna type | 2×2 |
| Network | |
| Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11n |
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Ethernet LAN interface type | Gigabit Ethernet |
| Outdoor range | 5+ km |
| Frequency band | 5 GHz |
| Ports & interfaces | |
| Ethernet LAN | Yes |
| Connectivity technology | Wired & Wireless |
| Ethernet LAN (RJ-45) ports | 2 |
| Power over Ethernet plus (PoE+) ports quantity | 1 |
| Security | |
| Security algorithms | WPA2-AES |
| Features | |
| Product type | Network bridge |
| Material | Polycarbonate (PC), Stainless steel |
| Product colour | White |
| Reset button | Yes |
| International Protection (IP) code | IPX6 |
| Power LED | Yes |
| LED indicators | LAN, Power, Signal strength |
| Mounting type | Pole |
| Power | |
| Power consumption (max) | 9 W |
| Power source type | DC, PoE |
| DC input voltage | 42.5 – 57 V |
| Power over Ethernet (PoE) | Yes |
| Power over Ethernet (PoE) voltage | 48 V |
| Operational conditions | |
| Operating temperature (T-T) | -40 – 60 °C |
| Operating relative humidity (H-H) | 5 – 95% |
| Management features | |
| LED indicators | LAN, Power, Signal strength |
| Certificates | |
| Compliance certificates | CE, Federal Communications Commission (FCC), Industry Canada (IC) |
| Technical details | |
| Material | Polycarbonate (PC), Stainless steel |
| Product colour | White |
| Quantity per pack | 1 pc(s) |
| Compliance certificates | CE, Federal Communications Commission (FCC), Industry Canada (IC) |
| Weight & dimensions | |
| Weight | 515 g |
| Width | 189.5 mm |
| Depth | 64.3 mm |
| Height | 189.5 mm |
| Indication | |
| Power LED | Yes |
| Packaging content | |
| Cables included | AC |
| Mounting bracket(s) included | Yes |
| Power supply included | Yes |
| Packaging data | |
| Quantity per pack | 1 pc(s) |
