| Specification |
| Data transmission |
| Maximum data transfer rate |
4800 Mbit/s |
| Performance |
| 2.4 GHz |
Yes |
| 5 GHz |
Yes |
| Reset button |
Yes |
| Web-based management |
Yes |
| VLAN support |
Yes |
| Quality of Service (QoS) support |
Yes |
| Networking standards |
IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1Q |
| Certification |
FCC, IC |
| Maximum data transfer rate |
4800 Mbit/s |
| MIMO type |
Multi User MIMO |
| MIMO |
Yes |
| Network |
| Networking standards |
IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1Q |
| Management features |
| VLAN support |
Yes |
| Quality of Service (QoS) support |
Yes |
| Web-based management |
Yes |
| Certificates |
| Certification |
FCC, IC |
| Features |
| 6 GHz |
No |
| 2.4 GHz |
Yes |
| 5 GHz |
Yes |
| VLAN support |
Yes |
| Quality of Service (QoS) support |
Yes |
| Networking standards |
IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1Q |
| Maximum data transfer rate |
4800 Mbit/s |
| Bluetooth |
Yes |
| MIMO type |
Multi User MIMO |
| MIMO |
Yes |
| Maximum data transfer rate (2.4 GHz) |
573.5 Mbit/s |
| Maximum data transfer rate (5 GHz) |
4800 Mbit/s |
| Security |
| Security algorithms |
WPA, WPA-Enterprise, WPA-PSK, WPA2, WPA3 |
| Power |
| Power consumption (max) |
11 W |
| Power over Ethernet (PoE) |
No |
| Input current |
0.3 A |
| AC input voltage |
100 – 240 V |
| AC input frequency |
50 – 60 Hz |
| Design |
| Housing material |
Plastic |
| Placement |
Wall |
| Product colour |
White |
| Reset button |
Yes |
| LED indicators |
Yes |
| Certification |
FCC, IC |
| Antenna |
| Antenna gain level (max) |
6 dBi |
| Technical details |
| Reset button |
Yes |
| Indication |
| LED indicators |
Yes |
| Weight & dimensions |
| Width |
112.2 mm |
| Depth |
77.6 mm |
| Weight |
340 g |
| Height |
169.7 mm |
| Operational conditions |
| Operating relative humidity (H-H) |
5 – 95% |
| Operating temperature (T-T) |
-10 – 50 °C |
| Logistics data |
| Quantity per pack |
1 pc(s) |
|
